60,000 BTU - R410A - Single Zone Floor/Ceiling Console Ductless Air Handler
60,000 BTU - R410A - Single Zone Floor/Ceiling Console Ductless Air Handler
Model: Blueridge BM60MFCC
- 3D
- + 3 More
Model: Blueridge BM60MFCC
Provides heating and cooling
Whisper quiet indoors and outdoors
Sips electricity for low utility costs
Simple installation + friendly tech support available
$82000
Qty:
In Stock and Ready to Ship
If ordered by 1PM CST M-F, ships same day. All items on your order must be in stock for same-day shipping.
Includes
highlights
*IMPORTANT! This is an indoor air handler ONLY. You must have a matching Blueridge outdoor condenser to complete a functioning system.*
Why choose Wall/Ceiling Console?
This type of indoor unit can be mounted on the ceiling or wall, respectively, given the specificity of the planning and placement of objects in the room. The main distribution (flow) of air occurs only in 1 direction, the additional flow deviation to the side slats also provideguides with automatic adjustment, the deviation of air flow both vertically and horizontally, you can adjust the commands from the remote control that is present in the unit factory set.
Specs
System Information
Single Zone Mini-Split Series
XL1: XL Core / XL2: XL Extended Performance
Indoor Air Handler Type(s)
Floor Ceiling
Zones
1
Product Type
Floor Ceiling Air Handler
Single Vs. Multi-Zone
Single zone
Features
WIFI (2.4GHz)
Yes (With Adapter)
Wireless Remote
Included
Refrigerant Readiness
Primary Refrigerant
R-410A
Mobile Home Compatible
Yes
RDS (Refrigerant Detection System) On-Board
No
Performance
Tonnage
5 Ton(s)
High Output Cool
60000 BTU
Nominal Cooling Capacity
60000 BTU
High Output Heat
60000 BTU
Airflow Capacity
1384 / 1029 / 795 CFM
Sound Rating
39 / 50 / 55 Decibels
Air Handler Setpoint Range (Cooling)
62 - 86 °F
Air Handler Setpoint Range (Heating)
62 - 86 °F
Line Set Information
Lineset Compatibility Code
L05
Liquid Line Size (OD)
3/8 Inches
Suction Line Size (OD)
3/4 Inches
Line Set Connection Type
Flare
Product Dimensions
Width
64 24/25 Inches
Depth
9 1/4 Inches
Height
26 57/100 Inches
Product Weight
101.2 lbs
Shipping Weight
110 lbs
Important Measurements
Minimum Unit Clearance (Sides to Wall)
1.4 Inches
Minimum Unit Clearance (Bottom to Floor)
Minimum 0 Inches - Max 24 Inches
Minimum Unit Clearance (Front)
39.4 Inches
Warranty
Parts Warranty
5 Years
Certifications
Approved for US Region(s)
North / Southeast / Southwest
ENERGY STAR® Certified
Yes
Qualified Manufacturer ID (QMID)
R4M0
