30,000 BTU 16 SEER Mini Split Outdoor Condenser
Model: Blueridge BMKH30M-ND30
highlights
*This listing is for the condenser only - you must match to indoor components for functionality.*
<<br_header>>
<<br_att:395,527,971,37>>
Features
- High Efficiency Inverter Technology
- Gold Fin condenser extends the operating life of your machine by protecting the product from corrosive effects of outside air
- Intelligent sleep function that adjusts to your sleep pattern in order to maximaize your comfort and reduce energy costs
- Built-in fan delay functionality
- Air-Flow direction control
- Intelligent defrost reduces energy loss and defrost time by only defrosting when needed
<<kit_items>>
<<br_footer>>
Specs
Efficiency
SEER2
16 SEER2
SEER
16 SEER
EER
9.3 EER
HSPF
8.2 HSPF
Coefficient of Performance (at 47 F)
3.1 COP
Refrigerant Readiness
Primary Refrigerant
R-410A
Factory Precharge
164 Feet
Mobile Home Compatible
Yes
RDS (Refrigerant Detection System) On-Board
No
Performance
Tonnage
2.5 Ton(s)
High Output Cool
24000 BTU
High Output Heat
27000 BTU
Stages of Heat
Inverter
Stages of Cool
Inverter
Compressor Type
Inverter
Sound Rating
56 Decibels
Electrical Information
Power Requirements
230/208 Volts
Voltage
208 / 220 / 230 Volts
Frequency
60 Hz
Voltage Phase
1
Minimum Ampacity
26 Amps
Maximum Fuse/Breaker
40 / 45 Amps
Line Set Information
Liquid Line Size (OD)
1/4 Inches
Suction Line Size (OD)
3/8 Inches
Line Set Connection Type
Flare
Maximum Line Length per Zone
82 Feet
Maximum Height Difference
50 Feet
Product Dimensions
Width
37 1/5 Inches
Depth
15 3/5 Inches
Height
27 3/5 Inches
Footprint Mounting Holes (W x D)
22 x 14.5 Inches
Total Weight
148 Lbs
Warranty
Parts Warranty
1 Years
Compressor Warranty
5 Years
Certifications
Approved for US Region(s)
North / Southeast / Southwest
ENERGY STAR® Certified
No
Accessories
Enjoy free shipping on any accessories purchased with the Blueridge BMKH30M-ND30.
Electrical Disconnect
Alpine AG-DCT
Safety Non-Fused Electrical Disconnect
$2199
Electrical Whips
Alpine AG-WHP8
3/4 x 48 Inches, #8 Gauge Electrical Whip
$2999
Mini-Split System Accessories
Alpine AHMSA1
Adapter 5/16" x 1/4" for Ductless Mini-Split Systems
$1999
DiversiTech 230-MB17CW
(2-Pack) 17" Mounting Blocks with End Caps for Ductless Mini-Split Air Conditioner and Heat Pump Condensers
$4700
Documents
AHRI Certificate BMKH30M 16 SEER(PDF, 223 KB)- Bluridge BMKHM Multizone Owners Manual - Outdoor Unit(PDF, 3.07 MB)
- Blueridge Ductless Mini-Split Warranty(PDF, 180 KB)
